Incinerator Automatic Protection Operator(APO) Controller
PleaseRegister/Loginto see the price or send email to us get discount if possible([email protected])
Incinerator Automatic Protection Operator(APO) Controller
In 2020, a significant step was taken towards environmental management and waste control within the African Union Mission in Somalia (AMISOM) camp through the provision of five TS150 PLC incinerators. Here’s an overview of the main features and capabilities of these units:
Model: TS150 PLC
Key Components & Specifications:
-
Primary Combustion Chamber: Volume of 1570 liters with internal dimensions of 150x100x105 cm, designed for the initial burning of waste.
-
Secondary Combustion Chamber: With a volume of 750 liters, ensures further combustion at elevated temperatures to reduce emissions.
-
Smoke Filter Chamber: Included to minimize environmental impact by filtering out smoke and particulates.
-
PLC Control Case: Equipped with Programmable Logic Controller for precise control over the incineration process.
-
Chimney: A 10-meter stainless steel upgrade, provided at no additional cost, for effective smoke dispersal.
Operational Parameters:
-
Burn Rate: Capable of handling an average of 50-100 kg per hour.
-
Feed Capacity: Each feeding can accommodate approximately 750 kg of waste.
-
Temperature Control:
-
Primary Chamber: Operates between 800°C to 1000°C.
-
Secondary Chamber: Reaches temperatures from 1000°C to 1200°C, ensuring complete combustion.
-
-
Residency Time: Waste is exposed to high temperatures for at least 2 seconds to ensure thorough incineration.
Additional Features:
-
Voltage: Compatible with 210/230V at 50/60Hz.
-
Power: Consumes 0.9 kW when operational.
-
Feed Door: Size of 80×60 cm for ease of waste loading.
-
Temperature Monitoring: Equipped with digital displays for real-time temperature checks.
-
Temperature Protection: Safety features to prevent overheating or damage.
Physical Specifications:
-
Gross Weight: Approximately 8500 kg, indicative of a robust and durable build.
-
External Dimensions: 300x160x280 cm, not including the chimney, designed for stationary installation.
The deployment of these incinerators reflects a commitment to sustainable practices in military and peacekeeping operations, ensuring that waste management does not compromise the local environment or the health of the personnel involved.
This initiative not only aids in maintaining hygiene and sanitation but also in reducing the ecological footprint of military camps in sensitive regions like Somalia.
