Incinerator for Hosptials
|
Incinerator Items/Model |
HICLOVER TS2000(PLC) |
|
Feeding Door Location |
Top Loading |
|
Burn Rate (up to)
Incinerator Spare Parts
Incinerator Spare Parts
Incinerator Spare Parts
Incinerator Spare Parts
Incinerator Spare Parts
Incinerator Spare Parts
Incinerator Spare Parts |
500 kg/hour |
|
Control Mode |
PLC Automatic |
|
Primary Combustion Chamber |
8800Liters(8.8m3) |
|
Primary Combustion Chamber Internal Dimensions |
4000x1500x1470mm |
|
Secondary Combustion Chamber |
3000Liters(3.0m3) |
|
Feed Mode |
Manual/forklift/crane ***forklift/crane supply by local |
|
Voltage |
220-240V |
|
Power |
6.0Kw |
|
Burner Type |
Italy Brand Riello |
|
Diesel Oil Consumption (Ltrs/hour) |
40-50 |
|
N.Gas/LPG Consumption (m3n/hour) |
*** |
|
Temperature Monitor |
Yes |
|
Time to Temperature |
45-60 mins |
|
Temperature Thermometer |
Corundum Probe Tube, 1400℃Rate. |
|
Temperature Protection |
Yes |
|
Automatic Cooling |
Yes |
|
Automatic False Alarm |
Yes |
|
Automatic Protection Operator(APO) |
Yes |
|
System Testing Model |
Yes |
|
Time Setting |
Yes |
|
Progress Display Bar/Timing |
LCD Display |
|
Oil Tank |
200L |
|
Oil Tank Stand |
Yes |
|
Liquid level Display |
Yes |
|
Top Feeding Door |
4000x1500mm |
|
Chimney |
10Meter |
|
Chimney Type |
Stainless Steel 304 |
|
Operational Temperature |
850℃–1300℃ |
|
Average ash residue (%) |
3% |
|
Thermostatic Device |
Yes |
|
Residency Time |
2.0 Sec. |
|
Gross Weight(Average) |
24000kg(24.0Ton) |
|
External Dimensions(Main Body) |
6490x2000x6260mm |
|
1st. Chamber Composition Hot Face |
High Alumina Refractory Brick Thickness: ≥115 mm |
|
Composition 55% of Al203 |
|
|
1750°C Grade |
|
|
2nd. Chamber Composition Hot Face |
High Alumina Refractory Castable Wall Thickness: ≥150 mm |
|
60% of Al203 |
|
|
1790°C Grade |
|
|
Chamber Cold Face Material |
High Rate Refractory Ceramic Fiber 50mm |
|
Other Parts Hot Face Refractory |
Heavy Duty with steel fiber |
|
Burner operation |
Automatic On/Off |
|
Wet Scrubber |
Optional |
|
Top Loading Door |
YES |
|
Paint for outside face |
250°C Grade |
|
Sealing Material |
Refractory Ceramic Fiber |
|
CE Certificate |
CE(2006/42/EC,2014/30/EU |
|
ISO Certificate |
ISO9001:2015 |
Combustion Chamber Volume (m3): 8.8m3
Burn Rate*: up to 500kg per hour
hospital incinerator design
Average Fuel Consumption: 40 – 50 ltrs p/h
Time to Temp: 45-60 mins
Operational Temperature: > 850°C
Gas Retention in Secondary Chamber: 2 secs
Loading Method: TOP Load
Fuel Options: Light Oil or Gas/LPG
Electricity Supply: 110v or 230v
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes
PHYSICAL SPECIFICATIONS
incineration waste management
External Length (mm): 6490mm
External Width (mm): 2000mm
External Height (mm): 6260mm
Door Size (mm); 4000 x 1500
Shipping Weight: 24000kg
Operating Footprint: 58.41m2
Cool Touch Cladding: Yes
Based on available public news and regulatory reports, the number of medical waste incinerators in the United States has dramatically decreased over the past few decades. In 1988, it is estimated that there were over 6,200 such incinerators nationwide. Today, however, due to stricter environmental regulations and the adoption of alternative treatment methods (such as autoclaving and microwave treatment), only about 30 medical waste incinerators remain in operation in the U.S. citeturn1search4
This sharp decline reflects an industry-wide shift toward safer, more cost-effective, and environmentally friendly waste treatment technologies. The reduction―from thousands to a few dozen units―illustrates the impact of regulatory changes, public health advocacy, and innovations in waste management practices over the years.
While the exact number can vary slightly by source and over time, the consensus from recent articles is that the current operating count is on the order of a few dozen, underscoring a major transformation in how healthcare waste is treated in the United States.
