Model TS10 Incinerator with wet scrubber (Spray Tower) and Defogging Tower

Incinerator Items/Model	HICLOVER TS10(PLC)
Burn Rate (Average)	10-20 kg/hour
Feed Capacity(Average) Quick View Related Products 100Liters-Vertical Pressure Steam Sterilizer-Autoclave-Digital Display Automation Quick View Related Products 120Liters-Vertical Pressure Steam Sterilizer-Autoclave-Digital Display Automation Quick View Related Products 150Liters-Vertical Pressure Steam Sterilizer-Autoclave-Digital Display Automation Quick View Related Products 150Liters-Vertical Pressure Steam Sterilizer-Autoclave-Digital Display Automation Quick View Related Products 150Liters-Vertical Pressure Steam Sterilizer-Autoclave-Digital Display Automation Quick View Incinerator Spare Parts 19 Burnrer Pressure Regulating Valve FIO 4″ Quick View Incinerator Spare Parts 19 Burnrer Pressure Regulating Valve FIO 4″ Quick View Incinerator Spare Parts 19 Burnrer Pressure Regulating Valve FIO 4″ Quick View Incinerator Spare Parts 20 Burnrer Pressure Regulating Valve FIO 6″ Quick View Incinerator Spare Parts 20 Burnrer Pressure Regulating Valve FIO 6″ Quick View Incinerator Spare Parts 20 Burnrer Pressure Regulating Valve FIO 6″ Quick View Incinerator Spare Parts 21 Burnrer Pressure Regulating Valve FIO 1″	20kg/feeding
Control Mode	PLC Automatic
Primary Combustion Chamber	100L
Internal Dimensions	50x50x40cm
Secondary Chamber	50L
Smoke Filter Chamber	Yes
Feed Mode	Manual
Voltage	220V
Power	3.0Kw
Burner Type	Italy Brand
Oil Consumption (kg/hour)	6
N.Gas Consumption (m3n/hour)	***
Temperature Monitor	Yes
Temperature Thermometer	Corundum Probe Tube, 1400℃Rate.
Temperature Protection	Yes
Automatic Cooling	Yes
Automatic False Alarm	Yes
System Testing Model	Yes
Time Setting	Yes
Progress Display Bar	LCD Display
Oil Tank	200L
Oil Tank Stand	Yes
Liquid level Display	Yes
Feeding Door	30x30cm
Chimney	3Meter
Chimney Type	Stainless Steel 304
1st. Chamber Temperature	800℃–1000℃
2nd. Chamber Temperature	1000℃-1300℃
Residency Time	2.0 Sec.
Gross Weight	1800kg
External Dimensions	140x90x120cm(Incinerator Mainbody)
1st. Chamber Composition Hot Face	Thickness: ≥115 mm
	55% of Al203
	1750°C Grade
2nd. Chamber Composition Hot Face	Thickness: ≥115 mm
	75% of Al203
	1790°C Grade
Chamber Cold Face Material	High Rate Refractory Ceramic Fiber
Other Parts Hot Face Refractory	Heavy Duty with steel fiber
Burner operation	Automatic On/Off
Dry Scrubber	Including
Wet Scrubber	Optional
Top Loading Door	Optional
Paint for outside face	250°C Grade
Sealing Material	Refractory Ceramic Fiber
Upgrade Containerized Mobile Type	Optional
CE Certificate	CE(2006/42/EC,2014/30/EU
ISO Certificate	ISO9001:2015
High-tech Enterprise Certificate	Yes

Establishing a pet cremation facility requires careful planning and the selection of appropriate equipment to ensure efficient and respectful services. Below is an overview of the essential equipment and technical considerations for setting up a pet crematorium:

Essential Equipment for a Pet Crematorium

1. Pet Cremation Furnace: The core of the operation, designed to handle various pet sizes and types. For instance, the HICLOVER A600 PLC is a front-loading pet cremator with a chamber size of 0.36m³, suitable for domestic animals such as birds, cats, and dogs. https://www.ctwai.net/products/#!/Pets-Cremation-Equipment-Model-A600-Oil/p/416008289
2. Refrigeration Units: Essential for the temporary storage of deceased pets before cremation, ensuring they are preserved in a dignified manner.
3. Processing Equipment: Post-cremation, the remains need to be processed into fine ash. An industrial processor is required for this purpose. https://www.ctwai.net/products/#!/Pet-Bone-Crusher-Shredder-with-vacuum-cleaning-function/p/713955274
4. Emission Control Systems: To meet environmental regulations, incorporating emission control systems is crucial.
   https://www.ctwai.net/products/#!/Model-TS10-Incinerator-with-wet-scrubber-Spray-Tower-and-Defogging-Tower/p/472484002
5. Safety Gear: Protective equipment such as aprons, gloves, and goggles is necessary for staff safety during operations. https://www.ctwai.net/products/#!/High-Temperature-Protection-Gloves/p/416004684

Technical Requirements and Customization Considerations

When collaborating with a cremation furnace manufacturer, consider the following technical specifications and customization options:

• Chamber Size and Capacity: Ensure the furnace can accommodate the typical sizes of pets served. For example, the HICLOVER A600 or TS50 has a chamber size of 0.36-0.58m³, suitable for domestic animals.
• Fuel Type: Decide on the fuel source—diesel, natural gas, or LPG—based on availability and cost-effectiveness.
• Loading Mechanism: Choose between side, front, or top-loading designs based on facility space and operational workflow.
• Emission Control: Incorporate dry or wet scrubber systems to manage smoke and odors, ensuring compliance with environmental standards.
• Automation Features: Opt for PLC control systems with intelligent sensors for continuous feeding and worker protection, enhancing operational efficiency.
• Heat Recovery: Consider furnaces with heat recovery functions to improve energy efficiency and reduce operational costs.
• Safety Features: Ensure the furnace includes high-temperature retention (HTR) capabilities, temperature monitoring, automatic cooling, and protection systems to safeguard operators.

By carefully selecting and customizing equipment to meet these specifications, a pet cremation facility can operate efficiently, safely, and in an environmentally responsible manner.
